Features

Vacuum turboemulsifiers suitable for processing liquid and creamy products from 600 to 10,000 litres with intermediate capacities.

VESSEL

  • Openable lid.
  • Static vessel.
  • Parts in direct contact with product in AISI 316 stainless steel (optional).

TEMPERATURE MANAGEMENT

  • Vessel with inner jacket filled with water/thermic fluids for heating and cooling,
  • Max. operating pressure in the inner jacket for heating/cooling 0,49 bar.
  • Insulation of the vessel by means of jacket.

VACUUM

  • Vacuum circuit with visual passage and liquid ring pump.

EQUIPMENT OF THE VESSEL

  • Funnel on the lid for auxiliary substances loading.
  • Sight-port equipped with glass-wiper and light-port with momentary light on the lid.
  • TriClamp connections on the lid.
  • Ball-type valves on the lid.

MIXER

  • Slow coaxial mixing system (counter-rotating).
  • Mixing blade with optimized profile for the vertical movement of product, including PTFE scrapers.
  • Variable speed of the Mixer through inverter.

TURBINE

  • Homogenizing turbine - rotor/stator type - at the bottom of the vessel.
  • Variable speed of the turbine through inverter.

VESSEL UNLOADING

  • Piston valve for the product unloading, placed at the bottom of the vessel.

SUPPORTING STRUCTURE

  • AISI 304 stainless steel supporting structure with anti-vibration/self-levelling and adjustable support feet.

OPERATOR PANEL

  • TOUCH 12" operator panel with Siemens PLC.
  • Digital visualization of the process parameters.
  • Function for the continuous recording of process parameters: TRENDS and DATALOGGER (D-SCRIBA).



Optionals



Only Openable options
